Hand-held Laser Welding System -W

The Handheld Laser Welding System -W is an integrated laser, water cooler and control unit with a portable welding head for easy laser welding work. Compared with traditional welding technology, laser welding has low heat input, not easy to produce thermal deformation and other advantages, and through swing welding can improve welding quality and productivity, welding fusion welding, wire welding and other welding methods, processing materials including stainless steel, galvanized sheet, low carbon steel, aluminum and copper and other metal materials.

Product Advantages


Easy To Learn And Operate


Ergonomic Hand Weldling Guns


Consistent High Quality Welding


Built-in Swing Welding


Low Requirements For Welders

Product Parameters

Hand-held Laser Welding System -W
Laser Power (W) 1000
Laser Wavelength (nm) 1080±10
Fiber Length (m) 10 (standard configuration)
Operating Mode Continuous/Modulation
Cooling Method Water Cooled
Working Environment Temperature (°C) 10-40
Working Environment Humidity (%) <70
Storage Ambient Temperature (°C) -10~60
Input Voltage  Single-phase AC 220V±10%
Dimensions (mm) 585X810X820
Equipment Weight (Kg) 125
Touch Screen Yes
Swing (mm) 0-5
Swing Frequency (Hz) 0~300
Welding Speed (mm/s) 0~50 (depending on the welding material)
Welding Head Weight (Kg) 1.7

Application Display
