Medium Frequency DC Resistance Welding Controller
Medium frequency DC controllers adopt modular design, used for spot welding, projection welding and seam welding of various metallic materials, widely used in automatic welding, manual welding, fixture spot welding system. Support primary/secondary current control, air cooling/water cooling optional, with flexible I/O interface.
Product Advantages
Product Parameters
| SMF Series Medium Frequency DC Resistance Welding Controller | |
| Input Voltage | 3phase AC 380V~480V±10% |
| Output Voltage | 1000Hz / 1800Hz / 6000Hz， PWM 500V |
| Duty Cycle(ED) | 10% |
| Maximum Output Current (A) | 400 / 600 / 800 / 1200 / 1600 / 2400 / 3600 |
| Cooling Method | Air Cooled/Water Cooled |
| Weld Schedule | 256 |
| Control Method | KSR/KUR/PHA/SAIRS |
| Secondary Feedback | Yes |
| Solenoid Valve Control | DC24V |
| Proportional Valve Control | 0~10V ， 4-20mA / 0~20mA |
| Ethernet Function | Yes |
| Fieldbus Option | Digital I/O / Profinet / Profibus / Devicenet / EIP / CClink |
