Medium frequency AC Resistance Welding Controller
Medium frequency AC controllers adopt modular design, used for spot welding, projection welding and seam welding of various metal materials, widely used in automatic welding, manual welding, fixed spot welding system. Support primary/secondary current control, air cooling/water cooling optional, with flexible I/O interface. No polarity effect, allowing reduced expulston.
Product Advantages
Product Parameters
| SVF Series Medium Frequency AC Resistance Welding Controller | |
| Input Voltage | 3phase AC 380V~480V±10% |
| Output Voltage | 15~400Hz ，PWM 500~650V |
| Duty Cycle(ED) | 5% / 10% |
| Maximum Output Current (A) | 400 / 800 / 1000 / 1200 / 1600 / 2400 / 3600 / 4800 |
| Cooling Method | Air Cooled/Water Cooled |
| Weld Schedule | 256 |
| Control Method | KSR/KUR/PHA/SAIRS |
| Secondary Feedback | Yes |
| Solenoid Valve Control | 24 |
| Proportional Valve Control | 0~10V ， 4-20mA / 0~20mA |
| Ethernet Function | Yes |
| Fieldbus Option | Digital I/O/ Profinet / Profibus / Devicenet / EIP / CClink |
